We are sorry but item below has been discontinued.

Ergotron SV41-41001 StyleView EMR Notebook Laptop Computer Cart, NonPowered

Be the first to review this product
Product ID: 16199
Recommended Accessories
Our Price: $1,448.80
Shipping: $95.95 *
Usually ships in 2 to 3 business days
* applies to Contiguous United States





Accessories for Ergotron SV41-41001 StyleView EMR Laptop Cart

Ergotron 97-466-214 Four-Outlet Power Strip with Medical-Grade Plug, receptacles

Ergotron 97-466-214 Medical-Grade Power Strip

Ergotron 97-464 Coiled Extension Cord Accessory Kit 97464

Ergotron 97-464 Coiled Extension Cord

Ergotron 60-590 Power Strip Mounting Kit for Ergotron Carts 60590

Ergotron 60-590 Power Strip Mounting Kit for Carts



Ergotron 60-575-003 T-Slot Bracket 60575003

Ergotron 60-575-003 T-Slot Bracket 60575003

Ergotron SRVC-CINP-01A StyleView Cart Integration for 10-99 Non-Powered Carts

Ergotron SRVC-CINP-01A StyleView Cart Integration

Ergotron SRVC-CINP-01B StyleView Cart Integration for 100/more Non-powered Carts

Ergotron SRVC-CINP-01B StyleView Cart Integration

Ergotron SRVC-PMPNO-01 One Year StyleView Cart Preventive Maintenance

Ergotron SRVC-PMPNO-01 Preventive Maintenance



Ergotron SRVC-PMNP-03 Three Year Preventive Maintenance for non-powered Carts

Ergotron SRVC-PMNP-03 Maintenance Maintenance

Ergotron SRVC-ANP-03A StyleView Cart Service Bundle for 10–99 Non-powered Carts

Ergotron SRVC-ANP-03A Bundle by Ergotron

Ergotron SRVC-ANP-03B StyleView Cart Service Bundle for 100 or more Non-powered

Ergotron SRVC-ANP-03B Service Bundle by Ergotron







General Information



Image of Warranty and Returns





Ergotron SV41-41001 StyleView EMR Notebook Computer Cart for Mobile Medical Applications, Non-Powered (white, grey and polished aluminum) SV4141001



Ergotron SV41-41001 StyleView EMR Notebook Computer Cart for Mobile Medical Applications









Description of Ergotron SV41-41001 EMR Cart:

This innovative, truly ergonomic and easy-to-maneuver healthcare cart features sit-to-stand height adjustment and an adjustable back-tilt keyboard tray.



Our years of experience and collaboration in point-of-care computing have enabled us to design a cart that nurses, IT, infection control and procurement will all love.









Technical Drawing for Ergotron SV41-41001 StyleView EMR Notebook Cart



Technical Drawing for Ergotron SV41-41001 StyleView EMR Notebook Cart









Technical Specifications:

     LCD Size

 Wt. Capacity

     Lift

Tilt

Pan

Rotation

VESA

up to 17"

up to 18 lbs
8 kg

20"
51 cm

- -

-

-







Product Information:

Part Number:

SV41-41001

Description:

StyleView EMR Laptop Cart, Nonpowered (white, grey and polished aluminum)

Included:

  • Worksurface

  • Secure Laptop compartment

  • Ethernet ready-on function and four-port USB hub

  • Scanner holder bracket

  • Mouse holder

  • Wrist rest

  • Back-tilt keyboard tray

  • Left/right mouse tray

  • Rear handle

  • Storage basket

  • Cable storage

  • Four casters (two locking)

Maximum Laptop Size:

15.5" W x 14.75" D x 2" H (393 x 375 x 51 mm)

Weight Capacity:

Total maximum load on height-adjustment assembly = 18 lbs (8 kg).

This is the sum of the following components: worksurface = ≤ 5 lbs (2.3 kg); keyboard tray = ≤ 3 lbs (1.4 kg); and laptop compartment = ≤ 10 lbs (4.5 kg)

Laptop and Worksurface:

Laptop and worksurface adjust 20" (51 cm) in tandem

True Ergonomics:

  • Ergonomic back-tilt keyboard tray with left or right mouse tray ensures wrists remain in a neutral position during data entry - avoid repetitive-stress injuries while increasing comfort and productivity

  • Designed for users 5'0" to 6'1" (152 to 185 cm) tall and for prolonged sitting or standing applications. Unlike competitive offerings, shorter users can work comfortably and productively in a seated position

  • Patented CF lift-and-pivot motion technology minimizes forces required to adjust cart position: Casters and height adjustment require just a touch

  • Actual cart weight is just 55 lbs (25 kg), making system relocation easy

Safe:

  • Surfaces are treated with Agion Antimicrobial for product protection; handles are smooth and continuous for improved cleanability

  • Environmentally clean: RoHS, REACH, WEEE and EU (94/62/EC) packaging compliant

  • Tested to UL/EN/IEC specifications for enhanced patient safety

  • Durable, easy-to-clean exterior composed of aluminum, high-grade plastic and zinc-plated steel promotes infection control

  • One-piece worksurface with no seams; easy-to-clean design promotes infection control

  • Lockable, ventilated enclosed storage for open laptop. Keys and locks are heavy-duty

  • Front-locking casters

  • Designed to meet guidelines established by the American National Standards Institute for computer use

Service:

Covered by Global Service Program - 24/7 coverage

All the Details Covered:

  • Notebook screen holders: Prevents the notebook screen from vibration for less damage to hinges over time

  • Universal mounting slot for accessories and equipment

  • A unique cable management system conceals and organizes cords, making cleaning easy

  • Ships fully assembled and is easily accessible from container

  • Four (4) ultra-smooth gliding casters for extremely easy push/pull mobility; two locking casters ensure lock-in-place stability

Compatibility and Dimensions:

  • Open-architecture design accommodates most laptops - even widescreen and allows for future hardware upgrades

  • Laptop Holder Internal Dimensions: 16" W x 14.9" D x 2.5" H (406 x 378 x 64 mm)

  • Compact Wheel-to-Wheel Base Dimensions: 17" x 21" (430 x 533 mm)

  • Worksurface Dimensions: 19.75" W x 19.6" D (502 x 498 mm)

Shipping Dimensions:

30.9" H x 21.3" W x 52.2" D (79 x 54 x 133 cm)

Shipping Weight:

81 lbs (36.8 kg), actual cart weight = 55 lbs (25 kg)

Warranty:

Five (5) years









Benefits of Ergotron SV41-41001:

    1.  Effortlessly maneuver the cart to the point of need - StyleView quickly responds to caregivers’touch and enables nurses to focus on their patients.



    2.  Truly ergonomic design accommodates the largest range of nurses and other caregivers; designed for sitting or standing with single-motion fluid adjustment - helps promote caregiver wellness and productivity.



    3.  Surfaces are treated with Agion Antimicrobial for product protection.



    4.  StyleView’s small footprint, with ultra-smooth gliding casters, travels easily across crowded carpet or hard surface floors and is perfect for space constrained areas.



    5.  Open-architecture design accommodates most laptops - even widescreen - easing future hardware deployments and upgrades.







Literature (Please open the following documents for more technical information)

Description

File Type

Ergotron SV41-41001 StyleView EMR Notebook Cart nonpowered - Product Sheet

- pdf

Ergotron SV41-41001 StyleView EMR Laptop Cart - Dimensional Illustrations

- pdf











Ergotron Logo



Hyperlink of all Ergotron products





Model SV41-41001
Manufacturer Ergotron
Part Number SV41-41001
UPC 698833012446
