Peerless DS-VW646-2x2 Universal 2x2 Video Wall Mounting Kit for 40" to 46" Displays up to 600 lbs

Compatibility Formula: Display must be at least 36” wide and 20.75” high. Width of the display + width of the mounting hole pattern < 1733 mm. Height of the display + height of the mounting hole pattern < 1136 mm
Be the first to review this product
Product ID: 17155
List Price: $919.83
Our Price: $840.99
You Save: $78.84
Shipping: $59.95 *
Usually ships in 1 to 2 business days
* applies to Contiguous United States
Add to Cart



Description

Creating a 2x2 video wall is simple and cost effective with the Peerless DS-VW646-2X2 video wall kit. The single wall frame design is quickly installed and then you’re ready to start hanging displays. Built in horizontal adjustment makes aligning displays easy. Due to the thin design, ADA compliance is a non issue with displays measuring 1.71" deep or less



Technical Drawing

Technical Drawing for Peerless DS-VW646-2x2 - 2x2 Video Wall Mounting Kit



Technical Specifications

Color

Black

Screen Size

40" to 46"

Weight Capacity

600lb (272kg)

Finish

Powder Coat

Product Dimensions

71.54" x 41.04" x 2.29" (1817 x 1042 x 58mm)

Weight

55lb (25kg)

Shipping Dimensions

Box 1: 72" x 4" x 4" (1829 x 102 x 102mm). Box 2: 45.75" x 17.125" x 4.25" (1162 x 435 x 108mm)

Shipping Weight

63lb (28.6kg)

UPC Code

735029281924

Package Contents

  • Wall Frame
  • Adapter Rails
  • Measuring plate and mounting hardware



Features

  • 2x2 video wall mounting kit
  • Horizontal adjustment makes mounting and aligning displays quick and easy
  • Compatible with most displays 40"-46"
  • Included security screws deter tampering and theft
  • ADA compliant with displays measuring 1.71" deep or less
  • Includes adapter rail alignment measuring plate to assist in the mounting of the displays
  • Fully VESA complaint



Literature (Please open the following documents for more technical information)

Product Sheet - Peerless DS VW646 2x2 Universal 2x2 Video Wall Mounting Kit

 - pdf

Installation Instructions - Peerless DSVW6462x2 VideoWall Mounting Kit up to 600 lbs

 - pdf



Model DS-VW646-2x2
Manufacturer Peerless Mounts
Part Number DS-VW646-2x2
Mounting Options Wall
