Ergotron 45-296-026 Height Adjustable Wall Mount Arm for TV, HD

Product ID 16877


  • Wall mount arm for TV
  • 20" height adjustability: TV can be lifted up and pulled down for a total of 20"
  • 17.5" horizontal adjustment: Side-to-side motion of 17.5" is possible
  • 24" extension: Extends 24" from the wall and retracts to 5.5" when not in use
  • 18-40 lbs weight capacity: Mounts a TV in the 18-40 lbs range
  • 30"-55" screen size: Supports TVs from 30" to 55" size
  • Smooth movement: Provides for smooth motion of TV in all directions
  • Please see if you want to mount a lighter TV or heavier TV

Animation of Ergotron 45-296-026 Height Adjustable Wall Mount Arm for TV, HD


Ergotron 45-296-026 is designed to adjust your TV in such a way that no matter where you are in the room, you always have the ideal viewing angle. With just a light touch, you can move the TV 20" vertically, 17.5" side-to-side and extend it 24" from the wall.

Accommodate the active TV positioning needs of today and tomorrow. Lift, swing or turn your display in any direction. Now anyone can effortlessly move their TV into multiple positions with only a light touch. Your screen will seemingly float on air, being easily adjusted between standing and seated heights. No more awkward viewing angles and sore necks.

Technical Drawing

Technical Drawing for Ergotron 45-296-026 Height Adjustable Wall Mount Arm for TV, HD

Technical Specifications

LCD size Capacity Lift Tilt Pan Rotation VESA
Screen Capacity Lift Tilt Pan Rotation VESA
30" - 55"

18 - 40 lbs

8.2 - 18.1 kg


50.8 cm

25° 180° 10° MIS-E/F

Product Information

Part Number 45-296-026
Description Interactive Arm, HD, Heavy Duty (polished aluminum)
  • Arm

  • Wall mount bracket

  • VESA adapter brackets

  • Complete hardware kit

Tilts Tilts forward 15°, tilts back 10°
Rotation Rotation of +/-5° provides leveling adjustment of screen in any position
Mounting Standards VESA FDMI MIS-E (hole pattern: 200 x 100 mm); VESA FDMI MIS-F (200–600 mm by 200–400 mm)
Note Due to the variety of wall constructions, consider using professional installers to attach this product. Professional installation is strongly recommended when attaching this product above fireplaces
Lock-Down Knob To fix the tilt position of the display in place, use the lock-down knob on the gravity pivot
Shipping Dimensions 26" x 12" x 7.5" (660 x 305 x 191 mm)
Shipping Weight 23 lbs (10.5 kg)
Warranty Five (5) years


  • Patented Constant Force technology enables light-touch adjustments

  • Extends 24" (61 cm) from wall when in use and can be fully retracted to 5.5" (14 cm) when not in use

  • The revolutionary design allows interaction with your TV by moving the screen to where you want it when watching movies, gaming, exercising and more

  • Provides smooth, continuous vertical and horizontal movement of the TV/display in all directions

  • Gravity pivot enables tilting capabilities without the need of knobs or levers

  • Improves ergonomic viewing for TVs/displays mounted high on the wall

  • Constructed from polished aluminum and black trim for maximum strength and bold aesthetics

  • Tilt and pan for maximum viewing flexibility

  • Level the screen at any position with +/- 5º of post-installation rotation

  • Cable management clips on the underside of the arm route and hide wires

  • Passes Ergotron’s 7,500-cycle motion test, which ensures a minimum of five years trouble-free height adjustment

Frequently Asked Questions

q Does this arm come in any other color than silver?

This arm comes only in color silver. The bottom part under the arm which is meant to cover the cables is Black and the plate that mounts to the back of the TV is also in color Black.

q We need a wall mount system capable of holding HP 23 pavillion all-in-one safely with maximum articulating capability. The model # of my monitor is 23-f250z.

This Interactive Arm, HD will work for your requirements. It has a 20" vertical, 17.5" horizontal adjustability and a 24" reach.

q I'm hoping to purchase this product to mount a flat screen tv. I want to be certain that this model wall mount will be the correct fit for my Samsung 40" TV Model #UN40J6300AF. Could you let me know for certain if this is the one I should get??

The Ergotron 45-296-026 Wall Mount Arm for TV will not work for you as a minimum of 18 lbs are needed on the arm while your monitor is 17.2 lbs. The one that will work for you is Ergotron Wall Mount Arm of TV, LD

Model 45-296-026
Manufacturer Ergotron
Part Number 45-296-026
UPC 698833021004
Weight Capacity 18-40 lbs (8.2-18.2 kg)
Lift (51 cm) 20 in
Tilt Forward 15 degree, back 10 degree
Pan 180 degree
Rotation 10 degree
Shipping Dimensions 26" x 12" x 7.5" (660 x 305 x 191 mm)
Shipping Weight 23 lbs (10.5 kg)
Warranty Five (5) years
Color Polished aluminum
Mounting Pattern VESA FDMI MIS-E (hole pattern: 200 x 100 mm); VESA FDMI MIS-F (200–600 mm by 200–400 mm)
Extend/Retract Range Extends 24" (61 cm) from wall when in use and can be fully retracted to 5.5" (14 cm) when not in use
Motion Adjustment 17.5" (45 cm) motion adjustment to either side
Mounting Options Wall
Monitor Size 30" and above
