Innovative Winston Dual Monitor Sit-Stand Workstation
For optimal performance, select the model that will support the total weight of your monitors and all items that will be placed on the Winston work surface. This will include your keyboard and mouse. The typical weight of keyboard and mouse is between 2-4 lbs. Please note, the monitor and the worksurface move in tandem, and not independent of each other.
Now includes Next Generation Tilter 8500 (not shown in the image). Please see Description for more details.
Description
Winston double monitor stand can mount two 30" monitors on a
freestanding base. With no drilling required, this adjustable
workstation is ideal for glass desktops. Easily move 10-26 lbs up to 17"
by simply pulling on the workstation with your hands to find your ideal
working height sitting or standing.
Winston sit-stand workstations encourage a healthier lifestyle. Standing
at work for even three hours a day can offer the same health benefits as
running 10 marathons a year, and even extend your life by two years.
Additionally, tabletop standing desktops can help counter several health
concerns caused by a sedentary lifestyle including obesity, type 2
diabetes, cardiovascular disease, and cancer.
The large but compact 30" x 18.3" work surface of this adjustable
monitor stand make it perfect for desks less than 24" deep. Include your
keyboard, mouse, phone, writing materials, and other necessary items
right on this dual workstation desk which was designed for stability to
eliminate a wobbly desk.
With a sleek, professional design Innovative's multi-monitor stand will
fit into several work environments and industries, including security,
IT, maintenance, gaming, programming, and designing.
Convert your desk to a healthy sit-stand workstation in minutes.
Winston Workstation dual freestanding sit-stand supports a two monitor
setup and features push-button height adjustment. Healthy sit-stand
workstation. Dual monitor mount. Compact work surface ideal for smaller
desks. Locking cylinder add stability, easy height adjustment.
Winston Workstation - Energizing your body. Inspiring your mind.
Instantly converts any desk into a sit-stand workspace boosting health
and productivity. Recent studies have shown that sitting throughout the
day can have the same negative health consequences as smoking. Winston
seamlessly integrates into your workday for a boost in health and
wellness. Winston Workstation now comes with a compact work surface,
ideal for users with smaller spaces who want to take advantage of a
healthy sit stand workstation.
Please note this monitor arm was updated in January 2022. The manufacturer, Innovative Design Works, has upgraded this part.
Tilter - A tilter is the part of the adjustable monitor arm that attaches to the back of your monitor and allows the monitor to rotate, pivot and tilt to desired position. This monitor arm is now available with Next Gen Tilter 8500. This new tilter apart from being slim and sleek has a quick release bracket, which makes installation and release easy and fast. It has a 30 lb weight capacity. However please bear in mind that the Next Gen Tilter 8500 comes with 100mm VESA adapter unlike the earlier standard tilter which comes with 75mm and 100mm adapter plate. If your monitor has only 75x75mm VESA pattern, please contact us through monitor arm finder. We will find the best monitor arm that matches your needs.
 8500 Quick Release Monitor Tilter |  8336 Standard Monitor Tilter |
Technical Drawing
Technical Specifications
| Color | 104 - Vista Black, 124 - Silver and 248 - Flat White |
| Height Adjustment Mechanism | Pneumatic |
| Screen Size | Up to 30" |
| Vertical Height Adjustment | 17" (43.2 cm) |
| Work Surface Size | WNST-2 - 23" x 30", WNST-2-CW - 17" x 30" |
| Weight Capacity | 10 - 26 lbs (4.5 - 11.8 kg) |
| Monitor Tilt | 200 degree |
| Monitor Pivot | Landscape to portrait |
| Mount Configurations | Freestanding |
| Monitor Compatibility | VESA 100mm |
| Cable Management | Cables are clipped to column |
| Warranty | 5 years |
Features
Quick, easy monitor install. Take the work out of adjusting and replacing monitors. Simply attach, adjust, and remove all at the face of the beam. No need to slide monitors to remove.
Engineered for stability. Designed to accommodate standing work without the distraction of unwanted movement.
Expansive work space. Large surface and convenient storage tray allow you to bring all necessities with you when you stand.
Upgrade your space. Retrofit your existing desk into a healthy workspace with two easy mounting options: freestanding or desk clamp.
Seamless height adjustment. Features a 17" range of vertical height adjustment and a locking cylinder to keep the workstation in place. No manual adjustment needed.
Cable management. Cable clips in the column and beam keep the cables organized and out of the way.
Ethical manufacturing. Winston is assembled in the USA using components created through a green manufacturing process.
VESA-monitor compatible - 100mm VESA adapter included.
Additional mounting options: clamp mount and thru mount also available.
Product Options/Accessories
Frequently Asked Questions
The WNST-2-CM-H refers to the desk clamp option, in which the Winston attaches to the edge of the desk. The "thru mount" also attaches the Winston to the desk but by drilling a hole in the desk.
This workstation has multiple mounting options (please see option 3 on page). A Freestanding base is included. There is also an option for a clamp mount and thru mount if you would like to use Grommet. The Freestanding base could be moved around wherever there is adequate desk space to accommodate the base, the clamp could of course only be clamped to edges of desk, and the thru-mount requires a grommet hole. The height between the monitor and keyboard tray is adjustable. The clamp around the column that is holding the horizontal beam the monitors rest on would need to be unscrewed. Once it is loosened, the clamp can be raised or lowered along the column to change the distance between the keyboard tray and the monitor.
| Model | WNST-2-124, WNSt-2-104, WNST-2-248 |
| Manufacturer | Innovative LCD Arms |
| Part Number | WNST-2-124, WNST-2-104, WNST-2-248 |
| Color | 104 - Vista Black, 124 - Silver, 248 - Flat White |
| Height Adjustment | Vertical 17" (43.2 cm) |
| Tilt | 200 degree |
| Mounting Pattern | VESA 100mm |
| Monitor Weight | 4 - 44 lbs (depending upon the model) |
| Suspended Keyboard | No |
| Desk Type | Desk Mount |
| Price | $700 - $799 |
| Weight Capacity | 10 - 26 lbs (4.5 - 11.8 kg) |
| Monitor Size | Up to 30" |
| Worksurface Dimensions | WNST-2: 30" W x 23" D. WNST-2-CW: 30" W x 17" D |
| Mounting Options | Freestanding, Desk Clamp, Thru-Desk |
| Height Adjustment Mechanism | Pneumatic |
| Warranty | 5 Years |
