Sit-Stand Wall Mount Dual Monitor Arm EDM-2201W

Product ID 19041
Sit-Stand Wall Mount Dual Monitor Arm EDM-2201W
Sit-Stand Wall Mount Dual Monitor Arm EDM-2201W


  • Dual monitor wall mount monitor arm
  • Provides 20" height adjustment to monitors
  • Holds 2 monitors weighing 5 to 11 lbs each with screen sizes from 17" to 24"
  • Extends displays 33", folds them within 5" of the back of the wall
  • Monitors can be adjusted 62" side-to-side
  • Ease of movement with handle


The ErgoDirect EDM-2201W is a versatile arm. Install this dual monitor wall-mount arm to quickly access data. With 20" height adjustment and 62" side-to-side movement, work on a project with a colleague or alternate between sitting and standing while working. The handle available at the bottom of the monitors makes it easier to move them as per your preference.

Technical Drawing

Technical Drawing for Ergotron 45-383-026 LX HD Sit-Stand Wall Mount LCD Arm

Product Information

Part Number EDM-2201W
Description Heavy Duty Sit-Stand Wall Mount LCD Arm (polished aluminum)
  • Sit-stand arm
  • Dual Monitor / Handle Kit
  • Extension
  • Wall-mount base
  • VESA brackets
Quality Tested 10,000-cycle test applied to lift mechanism, ensuring years of trouble-free height adjustment
Weight Capacity 5 to 11 lbs (6.3 to 13.6 kg). Monitor depth may affect weight capacity
Monitor Tilt 75° up and 5° down
Mounting Standards VESA MIS-D, 75/100 (hole pattern = 100 x 100 mm & 75 x 75 mm), MIS-E (hole pattern = 200 x 100 mm), MIS-F (hole pattern = 200 x 200 mm ONLY). Optional VESA Bracket Adaptor Kit (97-759) can be ordered separately for MIS-F interface with hole pattern of 400 x 200 mm, 400 x 300 mm or 400 x 400 mm
Locking Connections Between arm, extension and base offer increased theft deterrence and prevent potential disconnections caused by jarring or impacts
Mounting Options Attaches directly to sturdy vertical surfaces. Where applicable, install to wood stud. Also attaches to Wall Track using bracket (97-091, order separately)
Cable Management Clips on the under side of the arm route and hide cords
Base Includes theft-deterrent anchor holes for cable locks
NOTE Computer systems mounted on this product may require extra long USB, power or video cables in order to span between standing and sitting heights
Product Weight 21.9 lbs (9.93 kg)
Warranty Ten (10) years


  • 20" height adjustability allows users to alternate between sitting and standing positions while working on the display
  • Extends monitors up to 33" and pushes displays out of the way when not in use
  • Vertical, horizontal adjustability provides ergonomic relief and relieves stress on the back, shoulder and neck
  • Suitable for tight areas as it folds up to within 5" of the back of the wall
  • Increase viewing comfort - help reduce eye, back and neck strain
  • Upgrade LCD monitors and TVs with improved ergonomic adjustment
  • Patented CF motion technology provides premium ease-of-use adjustment
  • Cable management clips on the under side of the arm route and hide cords

Product Options/Accessories
