$130.00

Innovative 9110-HD Heavy Duty Monitor/TV Wall Mount

Product ID 19724

Related Products

Part Numbers Description
9110-HD Extension up to 4", Weight range up to 45 lbs
9110-HD-4 Extension up to 7.6", Weight range up to 40 lbs
9110-HD-8.5 Extension up to 11.1", Weight range up to 28 lbs
9110-HD-8.5-4 Extension up to 14.6", Weight range up to 22 lbs
9110-HD-8.5-8.5 Extension up to 18.1", Weight range up to 18 lbs

Description

Innovative 9110-HD series features our spring-assisted HD tilter for greater weight capacity and smoother monitor tilt adjustment. You can add optional extender arms to allow even greater flexibility and range.

Innovative 9110-HD-4 wall mount is ideal for hanging your computer monitor or flat screen TV to save maximum space. This flat panel wall mount allows pivot and tilt. The 9110-HD-4 wall mount enables the monitor or TV to pivot and tilt and includes a 4" extender arm.

Innovative 9110-HD-8.5 wall mount is ideal for hanging your computer monitor or flat screen TV to save maximum space. This flat panel wall mount allows pivot and tilt. The 9110-8.5 wall mount enables the monitor or TV to pivot and tilt and includes an 8.5" extender arm.

Innovative 9110-HD-8.5-4 wall mount is ideal for hanging your computer monitor or flat screen TV to save maximum space. This wall mount allows pivot and tilt and includes two extension arms (8.5" and 4").

Innovative 9110-HD-8.5-8.5 wall mount is ideal for hanging your computer monitor or flat screen TV to save maximum space. This wall mount allows pivot and tilt and includes two extension arms (8.5" and 8.5").

Offered in black only - inquire about upcharge for special color runs.

Technical Drawing

Technical Drawing for Innovative 9110-HD Heavy Duty Monitor/TV Wall Mount

Technical Specifications

ColorVista Black
Screen Size Up to 43"
Weight Capacity 9110-HD: Up to 45 lbs, 9110-HD-4: Up to 40 lbs, 9110-HD-8.5: Up to 28 lbs, 9110-HD-8.5-4: Up to 22 lbs, 9110-HD-8.5-8.5: Up to 18 lbs
Extension Range 9110-HD: Up to 4", 9110-HD-4: Up to 7.6", 9110-HD-8.5: Up to 11.1", 9110-HD-8.5-4 Up to 14.6":, 9110-HD-8.5-8.5: Up to 18.1"
TiltUp to 30° up and down
Pivot Landscape/Portrait
Rotation Varies
Mount Configurations Wall
VESA Compatibility75 & 100mm, adapter included
Warranty 10 years

Features

  • Robust: Includes our spring-assisted tilter for greater weight capacity and smoother monitor tilt adjustment.

  • Adjustable: This computer monitor and flat screen TV wall mount features adjustable tension at joints - ideal for touch-screen applications.

  • Easy: Easily pivot the monitor from portrait to landscape.

  • Flexible: Monitor can pivot from portrait to landscape.

  • Customizable: 9110-HD-4 includes 4" extension arm. 9110-HD-8.5 includes 8.5" extension arm. 9110-HD-8.5-4 includes 8.5" and 4" extension arms. 9110-HD-8.5-8.5 includes two 8.5" extension arms. Combine optional extension arms to increase reach.

Model 9110-HD
Manufacturer Innovative LCD Arms
Part Number 9110-HD
Color Vista Black
Monitor Size Up to 43"
Extension 9110-HD: Up to 4", 9110-HD-4: Up to 7.6", 9110-HD-8.5: Up to 11.1", 9110-HD-8.5-4: Up to 14.6", 9110-HD-8.5-8.5: Up to 18.1"
Tilt (up and down) up to 30 degree
Pivot Landscape / Portrait
Mounting Options Wall
VESA 75 & 100mm, adapter included
Weight Capacity 9110-HD: Up to 45 lbs, 9110-HD-4: Up to 40 lbs, 9110-HD-8.5: Up to 28 lbs, 9110-HD-8.5-4: Up to 22 lbs, 9110-HD-8.5-8.5: Up to 18 lbs
Warranty 10 Years
