Ergotron 97-906 WorkFit Single HD Monitor Kit

Be the first to review this product
Product ID: 18126
Highlights
  • Designed for use with WorkFit-T and WorkFit-D Sit-Stand models
  • Add this monitor kit to hold a monitor up to 30" in size
  • Weight capacity: 16 - 28 lbs
  • Vertical adjustment: 5"
  • Tilt: 30 degree
  • For a lighter monitor kit, please see  97-905
  • For a dual monitor version of this monitor kit, click here
Recommended Accessories
List Price: $170.00
Our Price: $99.00
Shipping: $12.75 *
Usually ships in 2 to 3 business days
* applies to Contiguous United States

Description

Upgrade your WorkFit to hold a larger LCD above the desktop. Ergotron 97-906 offers 5" (13 cm) of height adjustment and tilt. Easily lift and tilt the screen to proper height for unsurpassed ergonomic comfort.

For use with WorkFit-T, WorkFit-TL and WorkFit-PD products.

Technical Drawing

Technical Drawing for Ergotron 97-906 WorkFit Single HD Monitor Kit

Technical Specifications

LCD size Capacity Lift Tilt Pan Rotation VESA
Screen Capacity Lift Tilt Pan Rotation VESA
Up to 30"

16-28 lbs

7.3-12.7 kg

5"

12.7 cm

30° - 90° MIS-D/E/F

Product Information

Part Number 97-906 (replaces 97-665)
Description WorkFit Single HD Monitor Kit (black)
Includes
  • 5" lift engine

  • One (1) HD monitor pivot

  • Cable management tube and ties

  • Attachment hardware

Compatible

With WorkFit-T, WorkFit-TL and WorkFit-PD products

Weight Capacity 16-28 lbs (7.3-12.7 kg). When added to WorkFit-T, overall capacity of the WorkFit-T decreases from 35 lbs (15.9 kg) to 28.4 lbs (12.9 kg)
Mounting Standards

VESA FDMI, MIS-D, 75/100, C (hole pattern = 100 x 100 mm & 75 x 75 mm); VESA FDMI, MIS-E, C (hole pattern = 200 x 100 mm); VESA FDMI, MIS-F, C (hole pattern = 200 x 200 mm). For displays that use a 400 x 200 mm hole pattern, the VESA Bracket Adaptor Kit (97-474) can be ordered separately

Product Weight 6.6 lbs (3.6 kg)
Shipping Dimensions 25.2" x 5.0" x 6.9" (64 x 13 x 17 cm)
Shipping Weight 9 lbs (4.1 kg)
Warranty Five (5) years

Benefits

  • Holds display above worksurface, freeing up space

  • Cost-effective height-adjustable mounting solution

  • Simple installation and effortless operation

  • Patented CF motion technology provides premium ease-of-use display adjustment

  • Increase viewing comfort by reducing eye, back and neck strain

Model 97-906
Manufacturer Ergotron
Part Number 97-906
UPC 698833048988
Color Black
Monitor Size Up to 30"
Weight Capacity 16-28 lbs (7.3-12.7 kg)
Lift (12.7 cm) 5 in
Tilt 30 degree
Rotation 90 degree
Mounting Pattern VESA FDMI, MIS-D, 75/100, C (100 x 100 mm & 75 x 75 mm); VESA FDMI, MIS-E, C (200 x 100 mm); VESA FDMI, MIS-F, C (200 x 200 mm). For displays that use a 400 x 200 mm hole pattern, the VESA Bracket Adaptor Kit (97-474) can be ordered separately
Weight 6.6 lbs (3 kg)
Shipping Dimensions 25.2" X 5.0" x 6.9" (64 x 13 x 17 cm)
Shipping Weight 9 lbs (4.1 kg)
Warranty Five (5) years
