ISE Rise Electric 90 Degree Wing 3 Leg Height Adjustable Table
This product has been discontinued. See below for similar products we offer instead. We apologize for the inconvenience.
Similar Products
Description
The standing revolution has firmly taken hold, with ergonomists,
media, and governments all jumping on the bandwagon. From "sitting is
the new smoking" to "Is your chair killing you?", sitting disease is on
the lips of employees across North America.
Studies show that sitting all day at a fixed height work surface can
result in repetitive strain injuries, slowing metabolism and obesity.
Simply standing burns 60 more calories per hour than sitting.
It is not only healthier to regularly change from a seated to a standing
position, but studies prove that employees at height adjustable
workstations are significantly more productive. Employers save on churn
costs, decrease each employee’s real estate footprint and show a
commitment to worker well-being.
RISE is the solution. Its 22"-48" height range is ideal for large
companies who can standardize on one table to fit the vast majority of
employees. RISE is available in a wide range of configurations,
including 2 and 3-leg tables. The adjustable width frame expands and
contracts to fit worksurfaces from 48"-84", and is available in smaller
and larger sizes. The base can be customized to fit almost any size or
shape of worksurface.
Dimensions

Features
Electric Bosch German motors in each leg provide effortless adjustment
Anti-collision function automatically stops motors when table makes contact with an immovable object
RISE tables are the greenest tables on the market today, using less than 50 cents of electricity per year in standby
The unique frame design accommodates an adjustable keyboard system without spacers
Available with standard up/down switch or digital display switch with four memory positions
Specifications
Height range: 22"-48" from the floor to the top of a 1" worksurface
Width adjustable base allows one SKU to fit a large number of worksurface sizes (36"-48", 48"-84" or 84"-90")
Available in silver, white and black
Speed: up to 1.6" per second
Weight capacity: 225 lbs as standard (2-leg), 300 lbs upgrade available. 350 lbs (3-leg) distributed top load including worksurface
Power usage: 0.05W in standby / 84W in use
Certifications: UL, ANSI/BIFMA
Environmental: LEED MR 4.2, ID 1.1-1.4 eligible, worksurfaces Greenguard certified
Warranty: 10 years (electrical 3 years)
Option 1: Surface Dimensions
| Worksurface 24" x 54" ST-WIN-2454 and Frame Set SB-RISE-3-90 |
| Worksurface 24" x 60" ST-WIN-2460 and Frame Set SB-RISE-3-90 |
| Worksurface 24" x 66" ST-WIN-2466 and Frame Set SB-RISE-3-90 |
| Worksurface 24" x 72" ST-WIN-2472 and Frame Set SB-RISE-3-90 |
| Worksurface 24" x 84" ST-WIN-2484 and Frame Set SB-RISE-3-90 |
| Worksurface 30" x 42" ST-WIN-3042 and Frame Set SB-RISE-3-90 |
| Worksurface 30" x 48" ST-WIN-3048 and Frame Set SB-RISE-3-90 |
| Worksurface 30" x 54" ST-WIN-3054 and Frame Set SB-RISE-3-90 |
| Worksurface 30" x 60" ST-WIN-3060 and Frame Set SB-RISE-3-90 |
| Worksurface 30" x 66" ST-WIN-3066 and Frame Set SB-RISE-3-90 |
| Worksurface 30" x 72" ST-WIN-3072 and Frame Set SB-RISE-3-90 |
Option 2: Switch Type

Standard Control Switch

RISE-SWITCH-DRMS or RISE-SWITCH-DRMS-A
Push button up-down switch included or optional push button up-down switch with LED read-out display.
Option 3: Base Frame Colors
Option 4: Laminate Top Colors
Colors and patterns are representative only. Actual colors and patterns may vary slightly
Option 5: Edge Style
Edge Band Edge
T-Mold Edge
Option 6: Edge Treatment
Option 7: Casters - Wheels

RISE-GLIDESET-CARPET
Carpet Gripper Glide
Special glides for soft carpeted surfaces to provide extra grip
Compatible with RISE and Ascent bases
4 glides required for a 2-Leg base
Sold as a set of 4 glides
Black finish
Option 8: Power Strip

SA-PB-6-4 includes lighted surge indicator - 330 VAC Clamping / 270 joules - 6 receptacles - 4' cord length
SA-PB-8-6 includes lighted and audible surge indicator - 330 VAC Clamping / 1020 joules - 8 receptacles - 6' cord length
EMI-RFI Filters: SA-PB-6-4 /40 dB, SA-PB-8-6 /58 dB
Built-in surge protection
Intended for single station applications
UL/CSA Certified
Lighted rocker switch for on/off control
Includes 15 amp grounded power cord
Includes 15 amp Circuit Breaker
Fits all widths of Line-of-Sight Workstations
Includes mounting hardware
Frequently Asked Questions
No FAQs available for this product. Have a question? Ask us!
Product Information
- Model Rise Electric 90 Degree Wing 3 Leg
- Manufacturer ISE Ergonomics
- Part Number Rise Electric 90 Degree Wing 3 Leg
- Desk Type Electric
- Desktop Shape 90 Degree Wing 3 Leg
- Weight Capacity 350 lbs
- Height Range 22" - 48"
- Warranty 10 years (electrical 3 years)
