Chief K2C200 KONTOUR Column Clamp Mount, Dual Monitor

Part Number

Description

K2C200B

Black KONTOUR Manual Height Adjustment Column Desk Clamp Mount for Dual Monitors

K2C200S

Silver KONTOUR Manual Height Adjustment Column Desk Clamp Mount for Dual Monitors

Features of Chief K2C200 Series:

• Sleek, solidly-constructed forged aluminum arms.

• Independently position monitors for optimal viewing comfort (sitting and/or standing).

• Mounting arm slides vertically along column for ideal positioning.

• Tear-drop hold pattern for easy mounting and maintenance.

• Tool-free cable management covers for a clean, professional look.

• Patented Centris Turn-Tite Tilt. Tilts -15/+15 for a flexible ergonomic solution.

• Easily clamps to edge of desk (grommet and bolt through accessory available, separately).

Technical Drawing of Chief K2C200S or K2C200B KONTOUR Column Desk Clamp Mount for Dual Monitors

Description of Chief K2C-200:

Whether in the office, in healthcare facilities or at home, Kontour monitor arms create a more productive and comfortable workspace. Elegantly designed with a forged aluminum body, Kontour mounts will stand the test of time both functionally and aesthetically.

Specifications of Chief K2C 200:

Desktop Thickness Range:

0.5 - 3.25" (13 - 83 mm)

Manual Height Adjustment:

9.63"

Maximum Extension:

19.2" (487.7mm)

Minimum Depth:

2.98" (75.7mm)

Mounting Pattern Compatibility (Universal Versions):

75 x 75mm ,100 x 100mm

Number of Monitor:

2

Orientation:

Landscape, Portrait

Overall Dimensions (H x W x D):

17.0" x 14.8" x 3.0" (432 x 376 x 76mm)

Post-Installation Leveling (Roll):

Yes

Solution Type:

Universal

Tilt:

+ 15° , - 15°

TV Width Range:

10 - 28.8" (254 - 732mm)

Typical Screen Sizes:

10 - 30"

Weight Capacity:

25 lbs (11.3kg) per monitor
